Appendix A. Specifications
A.1 BHT-8000
[ 1 ] Product Specifications
Power Source Main power
• Two dry cells (alkaline manganese batteries), LR03
or
• Rechargeable Ni-MH battery cartridge (2.4 VDC)
Dimensions (W) x (L) x (H) 62 x 147 x 22 mm (2.4 x 5.8 x 0.9 inches)
Weight Approx. 160 g (Approx. 5.7 oz.) including dry cells or battery
cartridge
Operating Ambient Temperature -5°C to 50°C (23°F to 122°F)
Operating Humidity 20% to 80% (with no dew condensation)
Ambient Illuminance 20 to 10,000 lux.
(Depth of field: 160 mm, ITF: 1.0 magnification, PCS value: 0.9
min., Reflection intensity: 85% min. for white and 5% max. for
black)
Controller CPU: 32-bit RISC
RAM: 512KB
Flash ROM: 4MB
Keypad Function keys: 4
Magic keys: 8
Numerical keys and others: 16
Display
Type: Dot-matrix, FSTN liquid crystal display (LCD) with
backlight
Formation: 128 dots wide by 64 dots high
Screen mode Font size Chars x Lines Dots (W x H)
Standard-size 21 x 8 6 x 8
Single-byte
ANK* mode
Small-size 21 x 10 6 x 6
Full-width 8 x 4 16 x 16
16-dot font
Half-width 16 x 4 8 x 16
Full-width 4 x 4 32 x 16
16-dot font
(Double-width)
Half-width 8 x 4 16 x 16
Full-width 10 x 5 12 x 12
12-dot font
Half-width 20 x 5 6 x 12
Full-width 5 x 5 24 x 12
Two-byte
Kanji mode
12-dot font
(Double-width)
Half-width 10 x 5 12 x 12
*ANK: Alphanumerics and Katakana
Calendar Clock
Year, month, day, hour, minute, and second
Year: Two digits (with auto-correction on February 29 up to yea
2099)
Reading Confirmation LED
Colors: Red and green
EMC standard
VCCI Class B
