SERVICE MANUAL
Checkout and adjustments
(Rev. 0) RTG PLUS (120V)
7-5
S6:
S6:S6:
S6:
Cephalometric device (not applicable to PAN or ST version)
Cephalometric device (not applicable to PAN or ST version)Cephalometric device (not applicable to PAN or ST version)
Cephalometric device (not applicable to PAN or ST version)
It is OFF when the machine is preset for CEPH; it is ON when the
machine is equipped with the CEPH device.
To switch from OFF to ON and vice versa, simply press "s" (39).
This function must be set to ON when you add the cephalometric
device to a machine preset for CEPH.
To return to the normal working condition and store at the same
time the new configuration, press "R" (32). To access the next
function, press "T" (31).
S7:
S7:S7:
S7:
Display brightness
Display brightnessDisplay brightness
Display brightness
By pressing "s" (39), this function allows to adjust the brightness of
the display by choosing among a range of values from 0 (darkest
setting) to 7 (brightest setting).
To return to the normal working condition and store at the same
time the new configuration, press "R" (32). To access the next
function, press "T" (31).
S8:
S8:S8:
S8:
Reset
ResetReset
Reset
If this setting is ON, the RESET function (the return of the arm after
an exposure or after a TEST routine) will not be of "dead man" type,
but a single pulse through the "R" button (32) will be required to
obtain a complete arm travel.
To return to the normal working condition and store at the same
time the new configuration, press "R" (32). To access the next
function, press "T" (31).
S9:
S9:S9:
S9:
Pan deceleration ramp
Pan deceleration rampPan deceleration ramp
Pan deceleration ramp
If this setting is ON, the Child Pan function is set without
deceleration ramp (normal emission time = 14s).
When the display shows "S9 ON", press "s" (39) to change this
function to OFF (S9 OFF). You will thus configure the Child Pan
function with deceleration ramp (time = 15s).
To return to the normal working condition and store at the same
time the new configuration, press "R" (32). To access the next
function, press "T" (31).
With deceleration ramp inserted (parameter set to OFF), the
rotating arm will decelerate in the correspondence of cervical spine;
this will give a darker film at the canine/incisor area.
Our experience indicate that there is no need of this ramp for child
examinations.
