SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-6
SA:
SA:SA:
SA:
Tubehead angular position
Tubehead angular positionTubehead angular position
Tubehead angular position
When the display indicates "SA OFF", press "s" (39) to change this
function to ON (SA ON). You will thus be able to display the
tubehead angular position during the set-up phase only.
Press "R" (32) to display the actual angle.
Press "T" (31) to perform a Test function; the display will show the
rotating arm angular position reached (0°÷245°) during all run.
To return to 0°, press and keep pressed "R" (32).
To exit the set-up function, press "s" (39). The SA value will
automatically return to OFF (SA OFF).
SB
SBSB
SB:
::
:
TMJ examination enabling
TMJ examination enablingTMJ examination enabling
TMJ examination enabling
This function allows to make or disable the TMJ examination
feature.
NOTE:
On “ST” models, this function must not be enabled as the relevant
hardware is not installed on the unit.
SB=ON will allow the function, while SB=OFF will disable it.
Pressing the "s" (39) button changes the value.
The pressure of button "T" (31) will pass to the next parameter (in
this case returning to S0) storing the selected value, while pressing
the “X-ray emission” button (42) the set-up procedure will
terminate storing the set value.
NOTE:
At the pressure of TMJ1 or TMJ2 button while the SB=OFF value has
been stored, the message “TMJ function not allowed” will be visualised
on the display.
*
*
