SERVICE MANUAL
Checkout and adjustment
RTG PLUS (120V) (Rev. 0)
7-10
19. Press the "s" (39) key to change to SA ON.
20. Press the "R" (32) key: the display will show A (means angle)= 000.0°.
21. Pressing and holding "T" (31) key, perform a test rotation and check
that, during the rotation, the display will show a value increasing
smoothly and constantly corresponding to actual angular position of
the rotating arm; at the end of the rotation, the angle display will
show 245°.
22. Press the "s" (39) key.
23. Press the "R" (32) key to bring the arm in starting position.
