OPERATOR’S MANUAL

Control Point

11001-1489-201702 Rev B

SYSTEM INSTALLATION / 9

SYSTEM INSTALLATION

The Console mounts on the vehicle dashboard or other surface suitable for

operator viewing using a U-bracket. The standard (combination) mounting

plate secures the Switch Module immediately to the left of the Console. An

optional mounting plate mounts the Console only.

The Switch Module cable, which plugs into the Console, is long enough to

allow the Switch Module to be placed near the vehicle seat or elsewhere for

operator convenience. If the combination mounting plate is used, the option

remains to later remove the Switch Module from the mounting plate and to

relocate it for convenience.

The system main harness is laid out and connections are made to the

sensor and actuator cables, battery, ignition switch, and additional options

(two-speed axle, hopper level sensor, and boom sense inputs), as required.

Verify all items in the appropriate hardware mounting kit are present:

HARDWARE KITS

STANDARD HARDWARE KIT (46649-0380) FOR CONSOLE

AND SWITCH MODULE:

(1) Combination mounting plate (46649-0580)

(2) U-bracket (46649-0590)

(3) Two 1/4 - 20 x 1 inch hex bolts

(4) Five 1/4 inch split washers

(5) Two rubber washers (46390-0900)

(6) Two knob screws (20072-0022)

(7) Three 1/4 - 20 x 3/4 inch hex bolts

(8) Retaining clip (46649-0350)

(9) Two #6 self-locking hex nuts

(10) Three #6 plastite screws

OPTIONAL HARDWARE KIT (46649-0390) FOR CONSOLE

ONLY:

(1) Console mounting plate (46649-0370)
