22 / START-UP AND FAMILIARIZATION
Figure 14
Clearing Bottom Half of Current Totals Screen
ACCESSING THE SEASON TOTALS SCREEN
1. From the Operate screen, press the Console button and release after
the beep. Repeat until the Seasons Total screen appears (refer to
Figure 15). This screen shows the amount of material applied, miles
traveled during application, and hours elapsed this season for each
product in both the Auto and Blast modes. The totals can only be
cleared in the Program Mode (keyboard).
Figure 15
Season Total Screen
USING THE BLAST BUTTON
Pressing the red Blast button (on the left side of the Switch Module) causes
material to dispense at a higher, programmed rate. The BLAST button
performs several functions, depending upon programming options.
1. With the Operate screen displaying, press the Blast button on the side
of the Switch Module.When the Blast button is pressed, the Operate
screen displays BLAST ON above the Spread Width bar.This either
initiates a timed blast cycle (programmed length) or momentary (blasts
CURRENT TOTALS
PRESS DEC TO CONFIRM
CLEAR LIQUID 1 ACCUMS
LIQUID 1
GAL AUTO 2116.6
MILES AUTO 823.0
HOURS AUTO 26.10
GAL BLAST 197.0
MILES BLAST 68.4
HOURS BLAST 1.55
From CURRENT TOTALS Screen,
use Liquid +/– switch to change
(Press up to access, down to clear)
SEASON TOTALS
SALT
TONS AUTO 672.1
MILES AUTO 4938.2
HOURS AUTO 156.60
TONS BLAST 43.8
MILES BLAST 410.4
HOURS BLAST 9.35
LIQUID 1
GAL AUTO 12699.6
MILES AUTO 4938.2
HOURS AUTO 156.60
GAL BLAST 1182.3
MILES BLAST 410.4
HOURS BLAST 9.35
Access from OPERATE Screen
(Press Console Button 2/3 times)
To Next Page
