OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
KEYBOARD PROGRAMMING / 29
MISCELLANEOUS MENU (F12)
Before channel programming begins, a few basic settings require attention.
With the system ON and the keyboard connected, proceed as follows:
1. Press F12 function key to view the MISC Menu (refer to Figure 18).
Each item can be accessed by pressing the corresponding number key
on the keyboard.
Figure 18
Miscellaneous Main Menu
BLAST SETUP
2. From MISC MENU, press 1 on keyboard to select BLAST SETUP
(refer to Figure 19). Length of blast time and minimum ground speed
requires an entry.
BLAST TIMER – Determines the length of the BLAST cycle (0 to 99
seconds). When set to zero (0), the blast cycle lasts only as long as the
BLAST button is pressed.
BLAST SPEED – Establishes an artificial vehicle ground speed when
vehicle is at a standstill or moving slow that computes the rate material
dispenses during blasting. For speeds faster than this value, the actual
vehicle ground speed determines the spread rate. If Blast is set to zero,
the screen will show a BLAST, but no material will fall.
IMPORTANT: When the BLAST SPEED is set to zero, blasting cannot
be initiated with the vehicle stopped. The blast APR is
programmed from the material application rate functions
(F1, F4).
MISCELLANEOUS MENU
SELECT A MENU ITEM
1 BLAST SETUP
2 TIME / DATE
3 SYSTEM UNITS
4 SERIAL PORT CONFIGURATION
5 SERVICE MENU
6 MORE...
Press Function Key F12
to open MISC Screen
