38 / KEYBOARD PROGRAMMING
Figure 26
Road Temperature Screens
Alarm Temp 1-3
There are three user-definable temperature alarms to alert of road
temperature changes and that application rate or material changes may be
required. The temperatures must be entered in descending order with
Alarm Temp 1 the highest setting and Alarm Temp 3 the lowest setting.
Temp Hyst+
Temperature Hysteresis indicates the positive temperature changes that
has to occur above the active alarm temperature to clear the alarm. If
Alarm Temp 1 is 20 degrees F and the Temp Hyst+ is 5 degrees F, the
alarm activates when the temperature drops below 20 degrees F but clears
when the temperature reaches 25 degrees F.
High & Low Cal
High & Low Cal values are created from the calibration routine and are for
reference only and cannot be edited.
NOTE: Road Watch™ is a registered
trademark of Commercial
Vehicle Group™. Surface
Patrol technology is a
registered trademark of Control
Products, Inc.
TEMPERATURE SENSOR CALIBRATION
Press C to start the Temperature Sensor Adapter automatic calibration
procedure. Calibration lasts approximately 10 -20 seconds. Calibration is
complete when the Road Temperature Sensor menu displays.
IMPORTANT: The RoadWatch™ temperature sensor or Surface
Patrol™ temperature sensor must be disconnected and
the Temperature Sensor Adapter connected to the main
harness for successful calibration. If the Temperature
Sensor Adapter is disconnected when calibration is
performed, an error screen will display.
ROAD TEMPERATURE SENSOR
TEMP SNSR NO
ROAD TEMPERATURE SENSOR
TEMP SNSR YES
ALRM TEMP1 32.0 F
ALRM TEMP2 20.0 F
ALRM TEMP3 10.0 F
TEMP HYST+ 5.0 F
HIGH CAL 2.7 VOLT
LOW CAL 0.76 VOLT
PRESS C TO CALIBRATE
No Temperature Sensor
Road Temperature Sensor
To Next Page
