OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
START-UP AND FAMILIARIZATION / 21
Figure 12
Current Totals Screen
CLEARING THE CURRENT TOTALS
The ability to clear the Current Totals screen is programmable in the
Programming mode explained in the Keyboard Programming section. If
programmed, all totals on this screen should be recorded before clearing,
then proceed as follows.
1. With the Granular Switch ON, (upper screen), press the Granular +/-
(left) switch up and release when the beep sounds. A message
“PRESS DEC TO CONFIRM CLEAR (product) ACCUMS
(accumulators)” appears.
2. Press the same switch down (decrement) and the totals reset to zero
as shown in Figure 13. To clear the bottom half, repeat the steps for
the liquid channel with the Liquid +/- (right) switch (refer to Figure 14).
Press the console button to stop the clear operation.
Figure 13
Clearing Top Half of Current Totals Screen
CURRENT TOTALS
SALT
TONS AUTO 112.0
MILES AUTO 823.0
HOURS AUTO 26.10
TONS BLAST 7.3
MILES BLAST 68.4
HOURS BLAST 1.55
LIQUID 1
GAL AUTO 2116.6
MILES AUTO 823.0
HOURS AUTO 26.10
GAL BLAST 197.0
MILES BLAST 68.4
HOURS BLAST 1.55
Access with
Console Button
(Press until beep is heard - once/twice)
CURRENT TOTALS
SALT
TONS AUTO 112.0
MILES AUTO 823.0
HOURS AUTO 26.10
TONS BLAST 7.3
MILES BLAST 68.4
HOURS BLAST 1.55
From CURRENT TOTALS Screen,
use Granular +/– switch to change
(Press up to access, down to clear)
PRESS DEC TO CONFIRM
CLEAR SALT ACCUMS
To Next Page
