OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
KEYBOARD PROGRAMMING / 43
For Manual Entry - Select the Min Press text and enter the minimum
pressure voltage from the pressure sensors manufacturer’s specifications.
For Automatic Entry - The belly scraper MUST be off the ground and the
sensor installed prior to automatic entry. Select the Min Press text and
press “C” to capture sensor voltage.
Down Alarm is a user-definable percentage value of the maximum
pressure. An alarm activates when the pressure exceed the alarm limit.
BED HEIGHT SENSOR
The Bed Height sensors activates when the bed has exceeded the
recommended operating height.
The operator must inspect and maintain all mechanical linkage of
the sensor on a regularly scheduled interval to insure proper
operation of the bed height alarm. Visual inspection of the bed
height must be maintained as the primary indicator of safe bed
height operation. The alarm should only be used as a secondary
convenience indicator. The operator assumes all risk in using this
feature. DICKEY-john assumes no responsibility for alarm failure
to indicate an unsafe operating height.
BED HEIGHT SENSOR CONNECTION
Current Versions: Connect the Gate input on the current version main
harnesses.
Earlier Versions: Connect the Bed Height sensor to the Pressure input on
earlier versions of Control Point
®
main harnesses.
If the Gate Height is configured and the Bed Height sensor is enabled, the
Gate Height sensor automatically is disabled. The Bed Height sensor
feature must be enabled in the Control Point
®
console for activation.
Bed Height Sensor Activation: (F12) Misc, (6) More, (6) Bed Height
Sensor
