OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
44 / KEYBOARD PROGRAMMING
CONFIGURATION
NOTE: The Bed Height and Gate
Height sensors use the same
input, therefore both sensors
cannot be configured at the
same time.
Figure 30
Bed Height Sensor Screens
BED HEIGHT SENSOR CALIBRATION:
The Bed Down value indicates sensor voltage when the bed is completely
down. This value can be entered manually or automatically captured.
Manual Entry - Select the Bed Down text and enter the voltage from the
sensor when the dump bed is completely down.
Automatic Entry - The Dump bed must be completely down and the
sensor installed for automatic entry. Select the Bed Down text and press
“C” to capture the sensor voltage.
Bed Alarm indicates the voltage when the bed has exceeded normal
operating height and can be entered manually or automatically captured.
Manual Entry - Select the Bed Alarm text and enter the voltage when the
bed exceeds the normal operating height.
Automatic Entry - The dump bed must be near the maximum operating
height and the sensor installed before automatic entry can occur. Select the
Bed Down text and press “C” to capture sensor voltage.
The alarm will activate regardless of the master switch position.
BED HEIGHT SENSOR
ENABLED NO
BED HEIGHT SENSOR
ENABLED YES
BED DOWN 0.2 VOLT
BED ALARM 5.0 VOLT
SELECT POSITION THEN
PRESS C TO CALIBRATE
CURRENT VOLTAGE
PRESS D OR ESC WHEN DONE
Bed Height
Sensor Disabled
Bed Height
Sensor Enabled
To Next Page
