OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
54 / KEYBOARD PROGRAMMING
TANK CAPACITY
Tank Capacity indicates the maximum holding capacity of the tank. The
alarm is only active when the master switch is in the AUTO position. The
alarm will activate audible and visual signals when the tank level drops
below the Tank Alarm. When the master switch is turned OFF and then
returns to AUTO, the alarm will not be re-issued until the level goes above
the Tank Alarm plus the 5% hysteresis or until the unit has been turned off.
Figure 35
Tank Level Calibration Screen
TANK LEVEL CALIBRATION
BARGRAPH YES
TANK EMPTY 0.2 VOLT
TANK FULL 5.0 VOLT
TANK ALARM 5
SELECT POSITION THEN
PRESS C TO CALIBRATE
CURRENT VOLTAGE
PRESS D OR ESC WHEN DONE
TANK LEVEL CALIBRATION
BARGRAPH NO
TANK EMPTY 0.2 VOLT
TANK FULL 5.0 VOLT
TANK ALARM 25.0 GAL
CAPACITY 500.0 GAL
SELECT POSITION THEN
PRESS C TO CALIBRATE
CURRENT VOLTAGE
PRESS D OR ESC WHEN DONE
Bar Graph
No Bar Graph
