KEYBOARD PROGRAMMING / 35

Figure 24

Sensor Configuration Screen

SENSOR SELECTION

7. Select F12 to return to the Misc Menu and select the MORE MENU

screen pressing the 6 key, refer to (Figure 24).

MISCELLANEOUS MENU

SELECT A MENU ITEM

1 BLAST SETUP

2 TIME/DATE

3 SYSTEM UNITS

4 SERIAL PORT CONFIGURATION

5 SERVICE MENU

6 MORE.....

MISCELLANEOUS MENU

SELECT A MENU ITEM

1 GATE HEIGHT SENSOR

2 ROAD TEMPERATURE SENSOR

3 AIR TEMPERATURE SENSOR

4 12V BOOM SWITCHED OUTPUT

5 DOWN PRESSURE SENSOR

6 BED HEIGHT SENSOR

Select Item 6

from F12 Function Screen

(MISC Menu)

BED HEIGHT SENSOR

ENABLED NO

DOWN PRESSURE SENSOR

ENABLED NO

12V BOOM SWITCHED OUTPUT

ENABLED NO

AIR TEMPERATURE SENSOR

TEMP SNSR NO

ROAD TEMPERATURE SENSOR

TEMP SNSR NO

GATE HEIGHT SENSOR

GATEHEIGHT NO
