OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
14 / SYSTEM INSTALLATION
Figure 5
System Harness Layout
Gnd Speed
Sensor
Hopper Level
Sensor
+
Battery
Ð
Boom
Sensors
Flowmeter
Tank Level
or
Down Pressure
Granular
Application Rate
Sensor
Spinner
Sensor
Liquid
Valve
Granular
(& Spinner)
2 Speed Axle
Ignition
Alternate sets of connectors
(Insulate and tie back
unused connectors)
CPC connector
Main
Harness
12V Relay
Gate Height
Sensor
Road Watch
Adapter
