OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
KEYBOARD PROGRAMMING / 49
Figure 32
Setting Granular Application Rates (Step Method)
– APP START (Step method) – Defines the APR starting point.
– IC/DC STP (Step method) - Sets the increase/decrease step value.
– MIN APP (Step method) – Defines the minimum APR limit for the
product.
– MAX APP (Step method) – Defines the maximum APR limit for the
product.
– RATE 1 through RATE 10 (Rate method) – Defines up to ten
individual APR rates.
– BLAST RATE (Step or Rate method) – Defines a higher than
normal, spot-application rate applied when the red BLAST button is
pressed.
– CHNL LBL (Channel Label) (Step or Rate method) – Any product
material name of up to nine (9) characters can be keyed in.
Pressing the ENTER key stores the name for display on all granular
screens including the OPERATE screen wherever that material
appears in the event there is a data download.
4. Press F2 to return to the GRANULAR APPL RATE screen. If other
granular materials require programming, repeat the above procedures
for those materials.
APPLICATION RATE
SELECT A MENU ITEM
1 SALT ENABLED
2 SAND DISABLED
3 MIX A DISABLED
4 MIX B DISABLED
Press Function Key F2
(GRANULAR APPL RATE)
SALT APP RATES
ENABLE YES
STEP METHD YES
APP START 500.0 LBS / MILE
IC / DC STP 100.0 LBS / MILE
MIN APP 0.0 LBS / MILE
MAX APP 1200 LBS / MILE
BLST RATE 1200 LBS / MILE
CHNL LBL SALT
To Next Page
