OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
56 / KEYBOARD PROGRAMMING
The parameters for this screen are as follows:
Section 1-4
– SECTN ENBLED (Section Enabled) - Enter Y (YES) to enable the
boom section, N (NO) to disable.
– 12V On - Entering Y (YES) indicates +12 volts activates the section
solenoid. N(NO) means grounding activates the section solenoid.
– NUM OF NZZLS (Number of Nozzles) - Enter the number of
nozzles in the boom section.
– NZZLE SPCNG (Nozzle Spacing) - Enter the distance between
nozzles.
Section 4/Pause
– BOOM INPUT- This parameter only appears for Section 4. Entering
N (NO) activates Pause Enable that senses the position of an
optional add-on Pause Switch and its position.
– PAUSE ENABLE - The Pause switch will turn the material
application ON and OFF. Enter Y (YES) when using a
customer-supplied Pause Switch used to turn the material
application ON and OFF. Each time the pause switch shuts on and
off, an event occurs that tracks mileage with on/off time in the On/
Off History (F10) screen and is downloaded in the full spread
report.
NOTE: Boom Input and Pause Enable cannot both be set to Yes.
Section 5/Auto Anti-Icing
If the boom has been enabled to sense the position of a Pre-wet/
Anti-ice Switch, the Liquid channel (while in the OPERATE mode)
automatically switches between Liquid 1 (Pre-Wet) and Liquid 2
(Anti-ice) to avoid having to use the Material Select Screen to make
the change.
To use the Pre-wet/Anti-icing auto switch input feature, SECTION 5/
AUTO ANTI-ICING configuration must be set as follows:
–12V ON NO
–Boom Input NO
To use Section 5 for monitoring section 5 of a 5 section sprayer bar,
set as follows:
–Boom Input YES
Prewet/Anti-icing Switch and the Monitor Sprayer Section 5 cannot be
utilized simultaneously.
