OPERATOR’S MANUAL
Control Point
®
11001-1489-201702 Rev B
KEYBOARD PROGRAMMING / 59
Figure 38
Liquid Application Rates Setup (Automatic Granular Reduction)
4. Press F4 to return to the Liquid Appl Rate screen. If other liquid
materials require programming, repeat the above procedures for those
materials.
Note: All liquid parameter definitions are the same as granular except APR
measurements are in GAL/TON. If the liquid channel is anti-ice, APR units
are GAL/MILE instead.
IMPORTANT: Calibration is discussed in the next section. All
calibration constants not entered during programming
must be determined by performing the related
calibrations in the next section.
APPLICATION RATE
SELECT A MENU ITEM
1 LIQUID 1 ENABLED
2 LIQUID 2 DISABLED
3 LIQUID 3 DISABLED
4 LIQUID 4 DISABLED
LIQUID 1 APP RATES
ENABLE YES
STEP METHD NO
BLST RATE 12.0 GAL/TON
CHNL LBL LIQUID 1
Press Function Key F4
(LIQUID APPL RATE)
To Next Page
