OPERATOR’S MANUAL
Control Point ®
11001-1489-201702 Rev B
SYSTEM CALIBRATION / 83
Figure 49
Liquid Calibration
CALIBRATION MENU
SELECT A MENU ITEM
1 GRANULAR
2 LIQUID
3. SPINNER WIDTH
FLOWMETER CALIBRATION
SELECT A MENU ITEM
1 LIQUID ENABLED
2 LIQUID DISABLED
3 LIQUID DISABLED
4 LIQUID DISABLED
LIQUID 1 CALIBRATION
– – WARNING – –
THIS CALIBRATION
WILL ACTIVATE THE
SELECTED CHANNEL .
STARTING THIS
PROCEDURE WILL CAUSE
MATERIAL TO
DISPENSE .
CATCH MATERIAL IN
WEIGHED CONTAINER
PRESS R TO RUN
LIQUID 1 CALIBRATION
CALIBRATING
44910
PRESS S TO STOP
LIQUID 1 CALIBRATION
K-FACTOR 10000.00 P/GAL
COUNTS 53636
ENTER THE AMOUNT
DISPENSED IN
GALLONS
—
PRESS D WHEN DONE
Press Function Key F6
(CAL)
