Serial port Configure UDP serial mode
IX10 User Guide
222
13. Set the UDPport:
(config)> serial port1 udp port port
(config)>
The default is 4001.
14. (Optional) Enter a string that should be added at the beginning of each packet:
(config)> serial port1 udp socketid backslash-escaped-string
(config)>
15. Configure the remote sites to which you want to send data. If you do not specify any
destinations, the IX10 send new data to the last hostname and port from which data was
received. To add a destination:
i. Add a destination:
(config)> add serial port1 upd destination end
(config serial port1 udp destination 0)>
ii. (Optional) Enter a description of the destination:
(config serial port1 udp destination 0)> description string
(config serial port1 udp destination 0)>
iii. Set the host name or IP address of the remote site to which data should be sent:
(config serial port1 udp destination 0)>hostname hostanme-or-IP-
address
(config serial port1 udp destination 0)>
iv. Set the port number of the remote site to which data should be sent:
(config serial port1 udp destination 0)> port port
(config serial port1 udp destination 0)>
16. (Optional) Configure access control:
a. Return to the root configuration prompt by typing ...:
(config serial port1 udp destination 0)> ...
(config)>
b. Set the Access Control List:
n
To limit access to specified IPv4 addresses and networks:
(config)> add serial port1 udp acl address end value
(config)>
Where value can be:
l
A single IP address or host name.
l
A network designation in CIDR notation, for example, 192.168.1.0/24.
l
any: No limit to IPv4 addresses that can access the service-type.
Repeat this step to list additional IP addresses or networks.
