Digi IX10 User Manual

Routing Virtual Router Redundancy Protocol (VRRP)
IX10 User Guide
301
4. For Add VRRP instance, type a name for the VRRP instance and click .
The new VRRP instance configuration is displayed.
5. Click Enable.
6. For Interface, select Interface: ETH.
7. For Router ID, leave at the default setting of 50.
8. For Priority, type 80.
9. Click to expand Virtual IP addresses.
10. Click  to add a virtual IP address.
11. For Virtual IP, type 192.168.3.3.
Task 2: Configure VRRP+ on device two
1. Click to expand VRRP+.
2. Click Enable.
3. Click to expand Monitor interfaces.
4. Click  to add an interface for monitoring.
5. Select Interface: Modem.
6. Click to enable Monitor VRRP+ master.
7. For Priority modifier, type 30.
