Digi IX10 User Manual

Routing Virtual Router Redundancy Protocol (VRRP)
IX10 User Guide
303
6. For Custom gateway, enter 192.168.3.3.
7. Click Apply to save the configuration and apply the change.
Command line
Task 1: Configure VRRP on device two
1. Select the device in Remote Manager and click Actions > Open Console, or log into the IX10
local command line as a user with full Admin access rights.
Depending on your device configuration, you may be presented with an Access selection
menu. Type admin to access the Admin CLI.
2. At the command line, type config to enter configuration mode:
> config
(config)>
3. Create the VRRP instance:
(config)> add network vrrp VRRP_test
(config network vrrp VRRP_test)>
4. Enable the VRRP instance:
(config network vrrp VRRP_test)> enable true
(config network vrrp VRRP_test)>
5. Set the VRRP interface to ETH:
(config network vrrp VRRP_test)> interface /network/interface/eth
(config network vrrp VRRP_test)>
6. Add the virtual IP address associated with this VRRP instance.
(config network vrrp VRRP_test)> add virtual_address end 192.168.3.3
(config network vrrp VRRP_test)>
Task 2: Configure VRRP+ on device two
1. Enable VRRP+:
(config network vrrp VRRP_test)> vrrp_plus enable true
(config network vrrp VRRP_test )>
