Digi IX10 User Manual

Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
IX10 User Guide
426
2. Create an IPsec endpoint interface named ipsec_endpoint2:
a. Zone set to Internal.
b. Device set to Ethernet: Loopback.
c. IPv4 Address set to the IP address of the local GRE tunnel, 172.30.0.2/32.
3. Create a GRE tunnel named gre_tunnel2:
a. Local endpoint set to the IPsec endpoint interface, Interface: ipsec_endpoint2.
b. Remote endpoint set to the IP address of the GRE tunnel on IX10-1, 172.30.0.1.
4. Create an interface named gre_interface2 and add it to the GREtunnel:
a. Zone set to Internal.
b. Device set to IP tunnel: gre_tunnel2.
c. IPv4 Address set to a virtual IP address on the GRE tunnel, 172.31.0.2/30.
Configuration procedures
Configure the IX10-1 device
Task one: Create an IPsec tunnel
Web
1. Log into Digi Remote Manager, or log into the local Web UI as a user with full Admin access
rights.
2. Access the device configuration:
Remote Manager:
a. Locate your device as described in Use Digi Remote Manager to view and manage your
device.
b. Click the Device ID.
c. Click Settings.
d. Click to expand Config.
Local Web UI:
a. On the menu, click System. Under Configuration, click Device Configuration.
The Configuration window is displayed.
