Virtual Private Networks (VPN) Generic Routing Encapsulation (GRE)
IX10 User Guide
431
4. For Remote endpoint, type the IP address of the GRE tunnel on IX10-2, 172.30.0.2.
5. Click Apply to save the configuration and apply the change.
Command line
1. At the command line, type config to enter configuration mode:
> config
(config)>
2. Add a GRE tunnel named gre_tunnel1:
(config)> add vpn iptunnel gre_tunnel1
(config vpn iptunnel gre_tunnel1)>
3. Set the local endpoint to the IPsec endpoint interface created in Task two
(/network/interface/ipsec_endpoint1):
(config vpn iptunnel gre_tunnel1)> local /network/interface/ipsec_
endpoint1
(config vpn iptunnel gre_tunnel1)>
4. Set the remote endpoint to the IP address of the GRE tunnel on IX10-2, 172.30.0.2:
(config vpn iptunnel gre_tunnel1)> remote 172.30.0.2
(config vpn iptunnel gre_tunnel1)>
5. Save the configuration and apply the change:
(config vpn iptunnel gre_tunnel1)> save
Configuration saved.
>
Task four: Create an interface for the GRE tunnel device
Web
