Page 24 Operation 90030500B
ERR Receive Network error on packet
received, for example, CRC,
Frame, or FIFO overrun.
OVF Receive Overflow. Lights when
packets arrive faster than
PortServer II can process
them.
TX Transmit Lights when PortServer II is
transmitting a packet.
COL Transmit Lights when PortServer II
detects a collision on the net-
work. This may be a collision
between any packets, not nec-
essarily packets destined for
or originated by PortServer II
devices.
Signal Function Description
