Page 30 Installation 90030500B
Recommended maximum distance limitations
The maximum recommended length of each type of cable connection you may use
with PortServer II are shown below.
Note:
Although PortServer II may operate adequately if you exceed a given limita-
tion, performance may be degraded.
Ethernet
10BaseT
: Maximum distance of 330 ft (100 M) at a transmission rate of 10
megabits/second (10 Mbps).
10Base2
: Maximum distance of 610 ft (185 M) at a transmission rate of 10
megabits/second (10 Mbps).
EIA RS-232 serial ports
Maximum distance depends on the data rate and the type of cable:
V.24 cable
If you are connecting to a Frame Relay service, you require a fully V.24-compatible
cable. Distance limitations are the same as for serial cables.
Table 1 RS232 Serial Port Specifications
Data Rate (Baud) Distance (ft) Distance (M)
2400 200 60
4800 100 30
9600 50 15
19200 25 7.5
38400 12.5 3.8
57600 6.3 1.9
115200 3.2 0.9
