Command reference tables
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 44
DN
(v1.x80*)
Networking
{Identification}
Destination Node. Resolves an NI (Node Identifier)
string to a physical address. The following events
occur upon successful command execution:
1. DL and DH are set to the address of the module
with the matching Node Identifier.
2. “OK” is returned.
3. RF module automatically exits AT Command
Mode
If there is no response from a module within 200
msec or a parameter is not specified (left blank), the
command is terminated and an “ERROR” message is
returned.
20-character
ASCII string
-
CE
(v1.x80*)
Networking
{Association}
Coordinator Enable. Set/Read the coordinator
setting.
0 - 1
0 = End Device
1 = Coordinator
0
SC
(v1.x80*)
Networking
{Association}
Scan Channels. Set/Read list of channels to scan for
all Active and Energy Scans as a bitfield. This affects
scans initiated in command mode (AS, ED) and
during End Device Association and Coordinator
startup:
0 - 0xFFFF
[bitfield]
(bits 0, 14, 15
not allowed on
the XBee-PRO)
0x1FFE
(all XBee-
PRO
Channels)
bit 0 - 0x0B bit 4 - 0x0F bit 8 - 0x13 bit12 - 0x17
bit 1 - 0x0C bit 5 - 0x10 bit 9 - 0x14 bit13 - 0x18
bit 2 - 0x0D bit 6 - 0x11 bit 10 - 0x15 bit14 - 0x19
bit 3 - 0x0E bit 7 - 0x12 bit 11 - 0x16 bit 15 - 0x1A
Table 11: XBee / XBee-PRO commands - networking and security; sub-categories are designated within {brackets}
AT
Command
Command
Category Name and Description
Parameter
Range Default
