Digi XBee Product Manual

Command reference tables
XBee / XBee-PRO RF Modules 802.15.4 Product Manual 45
SD
(v1.x80*)
Networking
{Association}
Scan Duration. Set/Read the scan duration
exponent.
End Device - Duration of Active Scan during
Association.
Coordinator - If ‘ReassignPANID’ option is set on
Coordinator [refer to A2 parameter], SD determines
the length of time the Coordinator will scan
channels to locate existing PANs. If
‘ReassignChannel’ option is set, SD determines how
long the Coordinator will perform an Energy Scan to
determine which channel it will operate on.
‘Scan Time’ is measured as (# of channels to scan] *
(2 ^ SD) * 15.36ms). The number of channels to scan
is set by the SC command. The XBee can scan up to
16 channels (SC = 0xFFFF). The XBee PRO can scan
up to 13 channels (SC = 0x3FFE).
Example: The values below show results for a 13
channel scan:
0-0x0F
[exponent]
4
If SD = 0, time = 0.18 sec SD = 8, time = 47.19 sec
SD = 2, time = 0.74 sec SD = 10, time = 3.15 min
SD = 4, time = 2.95 sec SD = 12, time = 12.58 min
SD = 6, time = 11.80 sec SD = 14, time = 50.33 min
Table 11: XBee / XBee-PRO commands - networking and security; sub-categories are designated within {brackets}
AT
Command
Command
Category Name and Description
Parameter
Range Default

Digi XBee Specifications

General

Operating Frequency	2.4 GHz
RF Data Rate	250 kbps
Model	XBee S2C
Category	Control Unit
Operating Voltage	2.1 to 3.6V DC
Operating Temperature	-40 to +85 °C
Interface	UART
Dimensions	24.38 x 27.61 x 9.14 mm
