Digital Equipment VR320 - Removing the LED Cable from the Power Supply

Removing and Replacing FRUs 3–23
9. Disconnect the 3-wire, 5-pin LED cable
1
from the power supply
module by pressing the tab on top of the connector (Figure 3–20).
1
MA-1038-89.DG
1
3-Wire, 5-Pin,
LED Cable
To Video
Casting
Power Supply Module
Figure 3–20 Removing the LED Cable from the Power Supply
