Removing and Replacing FRUs 3–31
MA-1042-89.DG
Cable
Clamp
8-Wire,
8-Pin,
Brightness/
Contrast
Cable
Interconnect
Cable
Plastic
Tab
Plastic
Tab
Video
Casting
Assembly
Figure 3–26 Removing Cables from the Video Casting
