Digital Equipment VR320 - Color Bars I Pattern; Color Bars II Pattern

Alignment Screens A–5
A.5 Color Bars I Pattern
Use this 4-bar color pattern (Figure A–5) to check for the presence of all
colors, and to check if the colors are in the correct order.
BLUE RED GREEN WHITE
MA-X0935-88
Figure A–5 Color Bars I Pattern
A.6 Color Bars II Pattern
Use this 8-bar color pattern (Figure A–6) to check for the presence of all
colors, and to check if the colors are in the correct order.
BLACK BLUE RED GREEN CYAN YELLOW WHITE
MA-X0936-88
MAGENTA
Figure A–6 Color Bars II Pattern
