Digital Equipment VR320 - Removing the Power Supply

Removing and Replacing FRUs 3–25
12. Carefully slide the power supply module (with the two focus cables
still attached) out of the card guide (Figure 3–22).
13. Place the power supply on a flat surface close to the monitor.
MA-1031-89.DG
Black and
White Focus
Cables
Power
Supply
Module
Figure 3–22 Removing the Power Supply
