Digital Equipment VR320 - VR320 Deflection Adjustments

Aligning the Video Monitor 4–13
4.5 Deflection Adjustments
Figure 4–10 shows the location of the controls used to make the deflection
adjustments. Pull the deflection module out slightly to see the labels on
the controls.
MA-1053-89.DG
Deflection
Module
Pin
Trap
Width
VCen
VParab
HPhase
HParab
VHold
VLin
Height
HHold
HCen
HLin
Figure 4–10 Location of Deflection Adjustments
