4.5.8 Focus (FOCUS1, FOCUS2, DYN PHASE, HPARAB,
VPARAB)
Figure 4–24 shows the locations of the focus adjustment controls on the
power supply and the deflection module.
MA-1050-89.DG
Focus 1
Focus 2
Dyn
Phase
VParab
HParab
Figure 4–24 Focus Adjustment Controls
