Digital Equipment VR320 - Removing the Focus Wires

3–26 Removing and Replacing FRUs
14. Disconnect the white wire for focus 1 and the black wire for focus 2
from the focus pack (Figure 3–23).
NOTE
Carefully guide the power supply cabling when removing and
replacing the power supply.
MA-1039-89.DG
1
1
White Focus 1
Wire
Black
Focus 2 Wire
Power Supply Module
To Video
Casting
Figure 3–23 Removing the Focus Wires
