Removing and Replacing FRUs 3–29
7. Connect the 3-pin, 1-wire cable (P7) to J7 of the video casting
assembly.
8. Place the anode cable and dynamic focus cable in front of the power
supply before inserting the power supply in the card guides.
9. Slide the power supply in the card guides approximately 1/4 of the
way.
10. Place the focus 1 and focus 2 wires and the dynamic focus cable in the
cable clamp to the right of the video casting assembly.
11. Put the dynamic focus cable into the clamp on the rear wall of the
monitor behind the video casting assembly.
12. Connect the 5-pin, 3-wire LED cable.
NOTE
Handle the anode cable carefully and guide it when sliding the
power supply in the card guides.
13. Carefully slide the power supply in the card guides.
14. Connect the 4-pin, 4-wire power switch cable (P4) to J4.
15. Attach the 2-pin, 1-wire dynamic focus wire to the deflection module.
16. Connect the interconnect cable to the power supply (see Figure 3–15).
17. Connect the anode cable (P11) to the CRT and place the anode cable
into the cable clamp that is on the tube.
18. Tighten the screws on the power supply.
