DIGITAL-LOGIC AG PCCP5 Manual V2.3
11
Video Input: (option)
Controller: 65554 / 65555 from C&T
BUS: 32 Bit highspeed 33 MHz PCI bus
Videoinput Norm: 3 channels with PAL or NTSC (composite video sources = CVBS)
2 channels YC sources (=SVHS)
2 channels CVBS and 1 channel SVHS
V2.1A: may be programmed into the ITT VPX 3220A
Since V2.2: Philips SAA7111
Driversupport: DOS, WIN95 (demosoftware)
Resolution: 320 x 240 with 65554 / 69000
optional: 568 x 720 with 65555 or 69000
Capture speed: up to 30 images/second
PAL/NTSC Decoder: until V2.1A ITT VPX 3220A
since V2.2: Philips SAA7111A
Y-C resolution: 4:4:4 or 4:2:2 or 4:1:1
RGB resolution: 4:4:4 (16 Bit), gamma corrected
Mass Storage:
FD: Floppy disk interface, for max. 2 floppies, 34pin connector
HD: E-IDE interface, 40pin interface up to 12MByte fast IDE transferrates
SCSI Devices: PCI 10MB/s FAST SCSI-2 up to 7 devices, removable boot media
NCR 53C810 PCI SCSI controller
Standard AT interfaces:
Serial: Name FIFO IRQs Addr. Standard Option
COM1
COM2
yes
yes
IRQ4
IRQ3
3F8
2F8
RS232C
RS232C
RS422/RS485
RS422/RS485
(Baudrates: up to 115kBaud), RS485 is an assembling option
Parallel: LPT1 printer interface, in the EPP Mode bidirectional
Keyboard: PS/2
Mouse: PS/2
Speaker: 0.1W output drive
RTC: 146818A compatible RTC with CMOS-RAM 128Byte
Backup current:
< 5µA
Battery: Lithium 3V (48mAh)
LAN - Ethernet: (option)
Type: IEEE 802.3
Controller: SMC 91C94 / 96
Compatibility: ODI-Novell
Driver: ODI, packet-driver IEEE 802.3, NT3.5, OS/2, NDIS, NT4.0
Connector: 10Base-T (optionally assembled)
10Base-2 (standard assembled)
Data Rate: 10 MB/sec
Data-Bus: 16 Bit
Cable Type: RG/58A/U 50 ohms
Remote Boot Socket: none
RAM Buffer: 4k
Configuration: with EEPROM
