DIGITAL-LOGIC AG PCCP5 Manual V2.3
12
Sound I/O: (option)
Controller: Until V2.1A: AD1816 8Bit Soundblaster compatible
Since V2.2: ESS1869 8Bit Soundblaster compatible, with LM1877
Driver Support: DOS, WIN 3.11, WIN95, NT4
Output channels: Stereo Output Line Level
Input: Microphone, Line
Features: - Compatible with: SoundBlasterPro 8 Bit, AD-Lib,
MicroSoft-Windows Sound System
- OPL3 Synthesizer built in
- 3D Stereo Enhancement
- Digital mixer
- Game Port, Midi Interface
- Programmable IRQs, DRQs and I/O addresses
- Supports 16 Bit type F DMA playback
Supervisory:
Watchdog: LTC1232 with power-fail detection
USB external:
Controller: 430HX / PIIX3
Transferrate: 12.5MBps / 1.5 MBps
BUS internal:
PCI IEEE-996 standard bus, by Intel
Clock: 33MHz with 32bit data path and 100MB/s transferrate
BUS external:
ISA IEEE-996 standard bus
Clock: 8 MHz or programmable
Embedded BUS:
PC/104 IEEE-996 standard bus
Clock: 8 MHz or programmable
PC/104+ PCI 32bit, 33Mhz bus, this is an assembling option
Power Supply:
Working:
5 Volts ± 5%
Current: 3.4A nominal, using P5-166 MHz
Suspend: 2.5A
Rise Time:
>100µs from 0V to 4.75V
