DIGITAL-LOGIC AG PCCP5 Manual V2.3
13
Physical Characteristics:
Dimensions: Length: 200 mm / 7.9"
Depth: 120 mm / 4,7"
Height: 50 mm / 1.95"
Weight: 360 gr
PCB Thickness: 1.6 mm / 0.0625 inches nominal
PCB Layer: Multilayer
Operating Environment:
Relative humidity: 5 - 90% non condensing
Vibration: 5 to 2000 Hz
Shock: 10 G
Temperature:
Operating: Standard version: -25°C to +60°C
Enhanced temp. range: -25°C to +70°C -E27
Storage: -55°C to +85°C
Cooling:
Standard: 5V Fan, with feedback (frequency sensor)
Temperaturesensor: onboard, located in the center below the CPU
Option: passive with air flow > 1000ft/Min.
EMI / EMC (IEC1131-2 refer MIL 461/462):
ESD Electro Static Discharge: IEC 801-2, EN55101-2, VDE 0843/0847 Part 2
metallic protection needed, separate Ground Layer
included,15kV single peak
REF Radiated Electromagnetic Field: IEC 801-3, VDE 0843 Part 3, IEC770 6.2.9.
not tested
EFT Electric Fast Transient (Burst): IEC 801-4, EN50082-1, VDE 0843 Part 4
250V - 4kV, 50 ohms, Ts=5ns
Grade 2: 1KV Supply, 500 I/O, 5Khz
SIR Surge Immunity Requirements: IEC 801-5, IEEE587, VDE 0843 Part 5
Supply: 2 kV, 6 pulse/minute
I/O: 500 V, 2 pulse/minute
High-Frequency Radiation: EN55022
Compatibility:
PCCP5: mechanically compatible to standard ISA slot cards
Any information is subject to change without notice.
