DIGITAL-LOGIC MICROSPACE PCC-P5 - J61 PS;2 - keyboard connector; J6 VGA-CRT connector (HiDens DSUB 15 pin)

DIGITAL-LOGIC AG PCCP5 Manual V2.3
91
J61 PS/2 – keyboard connector
The keyboard connector, is a 6pin PS/2 connector that provides an interface for PS/2-keyboards.
J32
Pin
Keyboard
Signal
Pin 1 = Keyboard Data
Pin 2 = GND
Pin 3 = GND
Pin 4 = VCC , + 5 Volt
Pin 5 = Keyboard Clock
Pin 6 = GND
J6 VGA-CRT connector (HiDens DSUB 15pin)
Pin Signal
Pin 1 Red
Pin 2 Green
Pin 3 Blue
Pin 5 GND
Pin 6 GND
Pin 7 GND
Pin 8 GND
Pin 10 GND
Pin 13 H-Synch
Pin 14 V-Synch
