DIGITAL-LOGIC AG PCCP5 Manual V2.3
93
J56 Extended LCD connector
Pin Signal Function
Pin 1 VCC +5V
Pin 2 VGA-Red
Pin 3 VGA-Green
Pin 4 VGA-Blue
Pin 5 VGA-Horiz. Synch
Pin 6 VGA-Vert. Synch
Pin 7 Shiftclock
Pin 8 GND Ground
J38 SCSI connector (50pin RM2.54), (if this option is assembled)
Pin Signal Pin Signal
Pin 2 SCSI data 0 Pin 1 GND
Pin 4 SCSI data 1 Pin 3 GND
Pin 6 SCSI data 2 Pin 5 GND
Pin 8 SCSI data 3 Pin 7 GND
Pin 10 SCSI data 4 Pin 9 GND
Pin 12 SCSI data 5 Pin 11 GND
Pin 14 SCSI data 6 Pin 13 GND
Pin 16 SCSI data 7 Pin 15 GND
Pin 18 SCSI parity Pin 17 GND
Pin 20 GND Pin 19 GND
Pin 22 Terminator Pin 21 GND
Pin 24 GND Pin 23 GND
Pin 26 Terminator power Pin 25 GND
Pin 28 GND Pin 27 GND
Pin 30 GND Pin 29 GND
Pin 32 SCSI ATN Pin 31 GND
Pin 34 GND Pin 33 GND
Pin 36 SCSI BUSY Pin 35 GND
Pin 38 SCSI ACK Pin 37 GND
Pin 40 SCSI Reset Pin 39 GND
Pin 42 SCSI MSG Pin 41 GND
Pin 44 SCSI Select Pin 43 GND
Pin 46 SCSI CD Pin 45 GND
Pin 48 SCSI REQ Pin 47 GND
Pin 50 SCSI IO Pin 49 GND
J40 Ethernet coax connector 10BASE-2, (only if this option is assembled)
Pin Signal
Pin 1 EGND
Pin 2 Data
