DIGITAL-LOGIC MICROSPACE PCC-P5 - J31 Utility connector; J77 Video ZV Port

DIGITAL-LOGIC AG PCCP5 Manual V2.3
94
J31 Utility connector
Pin Function
Pin 1 PS/2 Mouse Data
Pin 2 PS/2 Mouse Clock
Pin 3 PS/2 Keyboard Clock (front connector)
Pin 4 PS/2 Keyboard Data (front connector)
Pin 5 Keyboard Clock intern (needs Matrix Controller or jumper J46)
Pin 6 keyboard Data intern (needs Matrix Controller or jumper J45)
Pin 7 VCC
Pin 8 GND
Pin 9 Speaker Output
Pin 10
Stereo Sound Output Left (1.3W at 8Ω LM1877, since V2.2)
Pin 11
Stereo Sound Output Right (1.3W at 8Ω LM1877, since V2.2)
Pin 12 Ground for Sound Output
Pin 13 Microphone Input
Pin 14 VBAT
Pin 15 GND
Pin 16 Reset in
J77 Video ZV Port
Pin Function
Pin 1 Video Port 0
Pin 2 Video Port 1
Pin 3 Video Port 2
Pin 4 Video Port 3
Pin 5 Video Port 4
Pin 6 Video Port 5
Pin 7 Video Port 6
Pin 8 Video Port 7
Pin 9 Video Port 8
Pin 10 Video Port 9
Pin 11 Video Port 10
Pin 12 Video Port 11
Pin 13 Video Port 12
Pin 14 Video Port 13
Pin 15 Video Port 14
Pin 16 Video Port 15
Pin 17 Ground
Pin 18 Serial Link Data I2C
Pin 19 Serial Link Clock I2C
Pin 20 Videoconverter Select
Pin 21 Horiz. Ref.
Pin 22 Vert. Ref.
Pin 23 Video Clock
Pin 24 Video Ready
Pin 25 Video Pixel Clock
Pin 26 VCC
