DIGITAL-LOGIC AG PCCP5 Manual V2.3
95
J62 Video Input
Pin Function
Pin 1 Video Input Channel 3 PAL or NTSC *
Pin 2 Video Input Channel 2 PAL or NTSC
Pin 3 GND
Pin 4 Video Input Channel 1 PAL or NTSC *
Pin 5 GND
Pin 6 Video Input for Y/C Sources, not used for PAL/NTSC
Since manualversion V2.26 VideoIN is corrected, as Philips chip differs to ITT in relation with the
SAAINIT.EXE tool.
J67 MIDI / GAME Port
Pin Function
Pin 1 VCC
Pin 2 Game Port A1
Pin 3 Game Port AX
Pin 4 GND
Pin 5 GND
Pin 6 Game Port AY
Pin 7 Game Port A2
Pin 8 VCC
Pin 9 VCC
Pin 10 Game Port B1
Pin 11 Game Port BX
Pin 12 MIDI OUTPUT
Pin 13 Game Port BY
Pin 14 Game Port B2
Pin 15 MIDI INPUT
Pin 16 not connected
J71 Audio Line Input
Pin Function
Pin 1 Left Line Input
Pin 2 Ground
Pin 3 Right Line Input
J90 SOUND AUX connector, new since V2.2
Pin Signal
Pin 1 Left
Pin 2 Right
J1 Cooler Power and Feedback
Pin Function
Pin 1 Ground
Pin 2 VCC
Pin 3 Feedback 5V TTL Signal (each turn of the fan should generate an impulse)
