E-VISION LASER 5000 SERIES USER MANUAL REV A JANUARY 2018
10
ITEM LABEL DESCRIPTION SEE PAGE
28.
Enters and confirms settings in the OSD.
MHL – Enter/Select/OK
22
29.
Navigates and changes settings in the OSD.
Quick Menu – For Horizontal Keystone.
MHL - Right
22
30.
MHL
Enables the MHL (Mobile High-Definition Link) technology feature for
smart devices.
31.
Forward in set increments for MHL.
32.
Play the following item on the programming list for MHL.
33.
Volume/1
Displays the Volume setting bar.
Number for Remote ID setting used. (see Note)
34.
Contrast/2
Displays the Contrast settings bar.
Number for Remote ID setting used. (see Note)
35.
Mute/3
Mutes the built-in speaker.
Number for Remote ID setting used. (see Note)
36.
Zoom/4
Displays the digital zoom settings bar.
Number for Remote ID setting used. (see Note)
34
37.
3D/5
Opens the OSD 3D Setting menu.
Number for Remote ID setting used. (see Note)
38.
Status/7
Opens the OSD Status menu (the menu only opens when an input
device is detected).
Number for Remote ID setting used. (see Note)
39.
Wired Jack Socket For connecting a wired remote to the projector.
Note:
Remote Combo Key Settings:
ID+0: Reset Remote Control customer code to default settings.
ID+1: Set Remote Control customer code to "1".
~
ID+7: Set Remote Control customer code to "7".
The Projector also requires its ID setting for unique control. For projector ID settings see page 42.
Note:
When the projector is in MHL mode, The keypad on the projector will be the same definition as the
corresponding keys on the remote control.
Controlling your connected smart device with the Projector keypad in MHL Mode:
MENU for App settings, Up, Down, Left and Right are used as directional arrows,
ENTER and EXIT.
Controlling your connected smart device with the remote control in MHL model:
When the projector projects the contents from your MHL compatible smart device, you can use the
remote control to control your smart device.
MENU for App settings,
Up,
Down, Left and Right are used as directional arrows,
ENTER and EXIT.
