page 94
Digital Projection M-Vision Laser 18K Series
Reference Guide
APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D October 2019
Standard
Resolution V-Freq (Hz) V-Total H-Freq (kHz) HDMI1/2 (*1) DisplayPort (*2) HB Dual- pipe HDMI (*3) HB DisplayPort (*3) Remarks Output Display Frame Rate
1080p25 Dual Pipe 1920x1080 25.00 1125 28.13 √ *5 100
1080p30 Dual Pipe 1920x1080 30.00 1125 33.75 √ *5 120
1080p50 Dual Pipe 1920x1080 50.00 1125 56.25 √ *5 100
1080p59 Dual Pipe 1920x1080 59.94 1125 67.43 √ *5 120
1080p60 Dual Pipe 1920x1080 60.00 1125 67.50 √ *5 120
WUXGA_60_RB Dual Pipe 1920x1200 60.00 1235 74.04 √ *5 120
