Digital Projection M-Vision Laser 18K Series
Connection Guide
SIGNAL INPUTS AND OUTPUTS
Rev D October 2019
3D Sync
3D Sync In
Sync input signal. Connect the 3D sync from your graphics card or server.
3D Sync Out
Sync output signal. This may be aff ected by the
Sync Offset setting in the 3D Control menu.
Connect this to your IR emitter or ZScreen.
Notes
3 4 5
6
3
3D input
4
3D Sync In
5
3D Sync OUT
6
IR emitter or ZScreen
1
3D Sync IN
2
3D Sync OUT
1
3D SYNC - OUT
RS-23212TRIGGER
2
