Digital Projection M-Vision Laser 18K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev D October 2019
Projector Overview
Front and rear views
1
Indicators: TEMP, LIGHT, STATUS and POWER
2
Lens mount
3
Air inlet
4
Lifting handle
5
Air inlet
6
Front infrared window
7
Stacking feet
8
Air outlet
9
Rear infrared window
10
Connections panel
11
Lifting handle
12
Control panel
13
Adjustable feet
14
Stacking feet
15
Mains socket and switch
Notes
Front view
5
3
2
1
76
4
Rear view
12108
14 1513
119
