3D menu
Use this menu to enable, disable and set up 3D input, as follows:
• 3D Format — Off, Auto, Side-bySide (half), Top and Bottom, Dual Pipe and
Frame Sequential.
Frame Sequential is displayed at the incoming rate whereas Dual Pipe is for
sources where Left and Right eye are delivered on separate inputs.
• DLP Link — Off / On.
DLP Link On emits a sync pulse for the 3D glasses via the projected image. DLP
Link Off will send the sync pulse to the sync out connector to use with an external
third party emitter.
• Eye Swap — Normal and Reverse (set to Reverse if the left- and right-eye images
are displayed in the wrong order)
• Dark Time — 0.65 ms, 1.3 ms and 1.95 ms. Set to reduce the eff ect of banding and
image overlapping when viewed through 3D the glasses.
3D Sync
• Offset — use the LEFT and RIGHT arrow buttons to compensate for image
overlappng (ghosting) when viewed through 3D glasses.
• Reference— External and Internal. This is information only.
Notes
.
If 3D Format is set to Off, all other
3D settings will be unavailable.
For further information about
supported 3D formats, see 3D
connections in the Connection
Guide.
When 3D is on, the following
settings become unavailable:
• Image > Picture Mode,
Dynamic Black, Freeze.
• Geometry > Digital Zoom,
Overscan.
• PIP > all settings.
See also
See also
3D types
3D types
and
and
Some 3D
Some 3D
settings explained
settings explained
further in this
further in this
guide.
guide.
See Appendix B: Supported
Signal Input Modes > 3D formats
in the Reference Guide for 3D
resolutions and frame rates.
