APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev D October 2019
Appendix B: Supported Signal Input Modes
2D formats
Signal Format Resolution H Freq. (KHz) Frame Rate (Hz) PCLK (MHz) DisplayPort
HDMI / HDBaseT
HD/SDI/3G
Remark
RGB YUV 8-bit YUV 10-bit YUV 12-bit
PC 640x480 31.469 59.94 25.175 X X VESA DMT
640x480 37.500 74.99 31.500 X X VESA DMT
640x480 43.269 85 36.000 X X VESA DMT
800x600 37.879 60.32 40.000 X X VESA DMT
800x600 46.875 75 49.500 X X VESA DMT
800x600 53.674 85.06 56.250 X X VESA DMT
848x480 23.674 47.95 25.000 X X VESA CVT
848x480 31.020 60 33.750 X X VESA DMT
1024x768 48.363 60 65.000 X X VESA DMT
1024x768 56.476 70.07 75.000 X X VESA DMT
1024x768 60.023 75 78.750 X X VESA DMT
1024x768 68.677 85 94.500 X X VESA DMT
1152x864 67.5 75 108.000 VESA DMT
1280x720 35.531 47.95 57.987 X X VESA GTF
1280 x 768 47.776 60 79.500 X X VESA DMT
1280 x 768 60.289 74.89 102.250 X X VESA DMT
1280 x 768 68.633 84.84 117.500 X X VESA DMT
1280 x 800 49.702 60 83.500 X X VESA DMT
1280 x 800 62.795 74.93 106.500 X X VESA DMT
1280 x 960 60.000 60 108.000 X X VESA DMT
1280 x 960 85.938 85 148.500 X X VESA DMT
1280x1024 63.981 60.02 108.000 X X VESA DMT
1280x1024 79.976 75.02 135.000 X X VESA DMT
1280x1024 91.146 85.02 157.500 X X VESA DMT
