Digital Projection M-Vision Laser 18K Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev D October 2019
Roll and pitch
The projector can be operated in any position, as shown in the illustration.
However, the following positions are to be avoided as they can reduce motor life:
Notes
Fig. 2 Positions to avoid
Lens facing down Inputs and outputs facing up
Pitch
360°
360°
Roll
Fig. 1 Roll and pitch - any position is possible
