Digital Projection M-Vision Laser 18K Series
Operating Guide
USING THE PROJECTOR
Rev D October 2019
Image menu
• Picture Mode
Choose from High Bright, Presentation and Video.
Use a diff erent setting depending the type of input source.
Press
ENTER/SELECT to open the list.
Use the UP and DOWN arrow buttons to select a picture mode from the list, then
press ENTER/OK to confi rm your choice.
Press EXIT to return to the main menu.
• Dynamic Black
Set to On to allow for increased contrast in darker scenes by modulating the light
source.
• Light Off Timer
When Dynamic Black is On, the Laser light source may turn off depending upon the
setting of the Light Off Timer. Options are: Disable, 0.5, 1.0, 1.5, 2.0, 3.0, 4.0
seconds.
• Gamma
Choose a de-gamma curve from 1.0, 1.8, 2.0, 2.2, 2.35, 2.5, S-Curve and DICOM.
Used correctly, the Gamma setting can improve contrast while maintaining good
details for blacks and whites.
If excess ambient light washes out the image and it is diffi cult to see details in dark
areas, lower the Gamma setting to compensate. This improves contrast while
maintaining good details for blacks. Conversely, if the image is washed out and
unnatural, with excessive detail in black areas, increase the setting.
S-Curve is an enhanced mid-tone gamma.
DICOM is a simulated DICOM display, which can be used for training applications.
• Brightness, Contrast, Saturation, Hue, Sharpness, Noise Reduction
Highlight the setting you wish to edit, and then press ENTER/OK, or the LEFT or
RIGHT arrow button to open the slider.
Use the LEFT and RIGHT arrow buttons to adjust the slider.
Press EXIT to close the slider and return to the menu, or MENU to close the slider
and return to the projected image.
• Freeze
Freezes the current frame.
• Resync
Press ENTER/OK to force the projector to resynchronise with the current input.
Notes
Dynamic Black
Gamma
Picture Mode
Brightness
Saturation
Hue
Contrast
Sharpness
Freeze
Noise Reduction
Off
2.2
High Bright
Resync
100
100
100
100
10
Light Off Timer ----
Off
Brightness
100
